Page #15 background imageLoading...
Page #15 background image
15Overview
Q
0.0001 99999
θd -179.99°~179.99°
θr -3.1416 3.1416
%
-99.999% 999.99%
Table2‐4 AT810AMeasurementRange
Parameter Measurement Range
L
0.001nH 9999.99H
C
0.001pF 9999.99mF
RXZ 0.00001Ω 99.9999M
BG 0.01nS 999.999S
D
0.00001 9.99999
Q
0.00001 99999.9
θd -179.999°~179.999°
θr -3.14159 3.14159
%
-999.999% 999.999%
2.3 TestSignal
2.3.1 TestSignalFrequency
AT2818: 10Hz300kHz
AT2816A: 50Hz200kHz
AT2816B: [37 Points]
50, 60, 80, 100, 120, 150, 200, 250, 300,400, 500, 600, 800,
1e3, 1.2e3, 1.5e3, 2e3, 2.5e3, 3e3, 4e3, 5e3, 6e3, 8e3,
10e3, 12e3, 15e3, 20e3, 25e3, 30e3, 40e3, 50e3, 60e3, 80e3,
100e3, 120e3, 150e3, 200e3
AT2817A : [16 Points]
50, 60, 100, 120, 200, 400, 500, 1e3, 2e3, 4e3, 5e3, 10e3, 20e3, 40e3, 50e3, 100e3
AT2817 : [10 Points]
50, 60, 100, 120, 1e3, 10e3, 20e3, 40e3, 50e3, 100e3
AT810A: 10Hz20kHz
Frequency Accuracy: 0.02%
2.3.2 TestSignalLevel
0.01V~2.00Vrms, 0.01V resolution.
Test Signal Accuracy: (10%+10mV)
2.3.3 Outputimpedance
30, 50 and 100,
Accuracy: 5%
2.4 MainFunctions
2.4.1 Correct ionFunction
OPEN/SHORT correction:
