19Startup
Figure3‐3 ConnecttoDUT
Do not apply DC voltage or current to the UNKNOWN terminals. Applying DC voltage or
current may lead to device failure. Connect the measurement sample (DUT) to the test port
(or the test fixture, cables, etc. connected to the test port) after the LCR meter has been
completely discharged.
