Page #16 background imageLoading...
Page #16 background image
16
AT2818/2816A/2816B/2817A/2817/810A User's Guide
Eliminates measurement errors due to stray parasitic impedance in the test fixtures.
LOAD correction
Improves measurement accuracy by using a calibrated device as a reference.
2.4.2 ComparatorFunction(Sorting)
Bin sort
The primary parameter can be sorted into BIN1-BIN9, AUX, OUT and HI/IN/LO for
each of the primary measurement parameters.
The sequential mode or tolerance mode can be selected as the sorting mode.
Limit Setup
Absolute value, deviation value, and % deviation value can be used for setup.
BIN count [*Not available in AT2817]
Countable from 0 to 999999
2.4.3 ListSweep
Points
There is a maximum of 10 points.
Sweep parameter
Test frequency, test signal voltage.
Comparator function of list sweep
The comparator function enables you to set one pair of lower and upper limits for each
measurement point.
You can select from: Judge with the first sweep parameter/Judge with the second
parameter/Not used for each pair of limits.
2.5 MeasurementAssistanceFunctions
2.5.1 Files
Up to 10 setup conditions can be written to/read from the built-in non-volatile memeory.
2.5.2 KeyLock
The front panel keys can be locked.
2.5.3 RS232
Complies with SCPI.
2.6 Options
2.6.1 USBhostport[*Option]
Universal serial bus jack, type-A (4 contact positions, contact 1 is on your left); female;
for connection to USB memory device only.
2.6.2 DCBiasVoltage
0V/1.5V/2V.
