23[Meas] Key
Table4‐5 AT2818Frequencyrangeandtestfrequencypoint
Frequency range(F) Resolution
10.0000Hz F 99.9999Hz
0.0001Hz
100.0000Hz F 999.999Hz
0.001Hz
1.00000kHz F 9.99999kHz
0.01Hz
10.0000kHz F 99.9999kHz
0.1Hz
100.000kHz F 300.000kHz
1Hz
AT2816A: 50Hz200kHz
Table4‐6 AT2816AFrequencyrangeandtestfrequencypoint
Frequency range(F) Resolution
10.0000Hz F 99.9999Hz
0.0001Hz
100.0000Hz F 999.999Hz
0.001Hz
1.00000kHz F 9.99999kHz
0.01Hz
10.0000kHz F 99.9999kHz
0.1Hz
100.000kHz F 200.000kHz
1Hz
AT2816B: [37 Points]
50, 60, 80, 100, 120, 150, 200, 250, 300,400, 500, 600, 800,
1e3, 1.2e3, 1.5e3, 2e3, 2.5e3, 3e3, 4e3, 5e3, 6e3, 8e3,
10e3, 12e3, 15e3, 20e3, 25e3, 30e3, 40e3, 50e3, 60e3, 80e3,
100e3, 120e3, 150e3, 200e3
AT2817A : [16 Points]
50, 60, 100, 120, 200, 400, 500, 1e3, 2e3, 4e3, 5e3, 10e3, 20e3, 40e3, 50e3, 100e3
AT2817 : [10 Points]
50, 60, 100, 120, 1e3, 10e3, 20e3, 40e3, 50e3, 100e3
AT810A: 10Hz~20kHz
Table4‐7 AT810AFrequencyrangeandtestfrequencypoint
Frequency range(F) Resolution
10.0000Hz F 99.9999Hz
0.0001Hz
100.0000Hz F 999.999Hz
0.001Hz
1.00000kHz F 9.99999kHz
0.01Hz
10.0000kHz F 20.0000kHz
0.1Hz
Frequency Accuracy: 0.02%
Procedure for setting test frequency [FREQ]
Step 1. Press the [Meas] key
Step 2. Use the cursor key to select [FREQ] field
Step 3. Use the soft keys or numeric entry keys to enter the test frequency.
When data is entered with the numeric keys, the soft keys change to unit labels (Hz, kHz)
Soft key Function
INCR ++ Refer to Table 4-8 AT2818’s Test Frequency that can be set
using INCR++/DECR-- and Table 4-9 AT2816X’s Test
Frequency that can be set using INCR++/DECR--
(*Note: not available in AT2817A and AT2817)
DECR --
INCR + Refer to Table 4-10, Table 4-11, Table 4-12 and Table 4-13
