Applent Instruments AT2818 User Manual

55Handler Interface
Table8‐2 Timing
Description
Time
MIN TYP MAX
t1 One Measurement Circle
FAST
100Hz - 180ms -
120Hz - 160ms -
1kHz - 67ms -
10kHz - 67ms -
100kHz - 67ms -
MED2
100Hz - 260ms -
120Hz - 225ms -
1kHz - 235ms -
10kHz - 235ms -
100kHz - 235ms -
SLOW
100Hz - 500ms -
120Hz - 425ms -
1kHz - 580ms -
10kHz - 580ms -
100kHz - 580ms -
t2 Trigger pulse width 1ms - -
t3 Trigger delay time -
25s
t4 AD Time (EOM)
FAST
100Hz - 164ms -
120Hz 136ms
1kHz 48ms
10kHz 48ms
100kHz 48ms
MED2
100Hz 240ms 250ms 260ms
120Hz 216ms
1kHz 232ms
10kHz 216ms 224ms
100kHz 216ms 224ms
SLOW
100Hz 460ms 480ms -
120Hz 400ms 420ms -
1kHz 560ms -
10kHz 540ms 560ms -
100kHz 540ms 560ms -
t5 Print Result Time 8ms - 8.8ms
t6 Handler out to EOM time -
10s
-
