37[Setup] Ke
y
Step 1. Move the cursor into the REF A field
Step 2. Enter the known value of the standard’s primary parameter using entry keys.
Step 3. Move the cursor into the REF B field, and enter the known value of the standard’s
secondary parameter.
Step 4. Connect the standard to the UNKNOWN terminal.
Step 5. Move the cursor into the FREQ # field
Soft key Function
OFF Disables this point.
CURRENT FREQ Use current frequency
MEAS OPEN Starts open correction.
MEAS SHORT Starts short correction
MEAS LOAD Starts load correction
Step 6. Press [MEAS LOAD] soft key.
During the measurement, an “LOAD measurement in progress” dialog message is shown
on the display.
When measurement has finished, the dialog disappears.
5.3 <LIMITTABLESETUP>Page
Press [Setup] key and press [LIMIT TABLE] soft key to open <LIMIT TABLE SETUP>
page.
This page allows you to configure the AT281x’s built-in comparator.
AT2818/AT2816X/AT2817A’s built-in comparator can sort DUTs into a maximum 10
levels (BIN1 through BIN9 and OUT) using up to nine sets of primary parameter limits
along with one set of secondary parameter limits.
AT2817A’s built-in comparator can sort DUTs into a maximum 4 levels (BIN1 through
BIN9 and OUT) using up to nine sets of primary parameter limits along with one set of
secondary parameter limits.
In addition, DUTs that fall within the primary parameter limits but are out of the
secondary parameter limits can be sorted into an auxiliary bin.
To take full advantage of the comparator, AT281x was equipped a handler interface for
use in conjunction with the comparator. All 14 bins signal can output to yours PLC via
the handler interface.
In the <LIMIT TABLE SETUP> page, you can configure each of the following controls
with the cursor placed in the corresponding field.
 Comparator ON/OFF [COMP]
*1
 Auxiliary bin ON/OFF [AUX]
*1
 Nominal value [NOM]
 Primary parameter comparator limit mode [MODE]
 Beep feature [BEEP]
*2
 Primary parameter total bins [BINS]
NOTE:
*1. This two setting also can be set in the <BIN NO. DISPLAY> page.
*2. This setting also can be set in the <SYSTEM CONFIG> page.
