AT2818/2816A/2816B/2817A/2817/810A User's Guide
Step 4. Use the soft keys to select list sweep parameter.
Soft key Function
FREQ[Hz] Uses frequency as the list sweep parameter
LEVEL[V] Uses voltage as the list sweep parameter
5.4.3 SweepPointandLimitModes
AT2817, AT2816X and AT2818’s List sweep measurement feature supports up to 10
sweep points as well as measurement limit values. Each of sweep point can be turned on
or off.
To configure the sweep points
Step 1. Press the [Setup] key
Step 2. Press the [LIST SETUP] soft key
Step 3. Use the cursor key to select one of the sweep point field ( 1 thru 10)
Step 4. Use soft keys to turn on/off current point.
Soft key Function
ON Turn on current point
OFF Turn off current point
Step 5. Enter the sweep point value (maybe the frequency value or signal level voltage value).
When you enter the frequency value, the soft key labels change to unit label (Hz, kHz).
When you enter the signal level voltage value, you don’t need to enter unit.
Step 6. Using the cursor keys, select the LMT field.
Step 7. Configure the limit parameter by pressing the appropriate soft key
Soft key Function
A Uses the primary parameter as the limit parameter.
B Uses the secondary parameter as the limit parameter.
- Turns OFF the limit feature.
Step 8. Using the cursor keys to select the LOW field
Step 9. Enter the lower limit value
Step 10. Using the cursor keys to select the HIGH field and enter the higher limit value.
Step 11. Repeat Step 4 to Step 10.
