AT2818/2816A/2816B/2817A/2817/810A User's Guide
15
The power of built-in 5k pull-up resistance of the output
signals.
19 /PHI Output
“Primary parameter beyond upper limit” signal.
This signal is output when the primary parameter ha
exceeded the upper limit for bins 1 to 9.
20 /PLO Output
“Primary parameter below lower limit” signal.
This signal is output when the primary parameter is below
the lower limit for bins 1 to 9.
21 /SREJ Output
“Secondary parameter out of limits” signal.
This signal is output when the secondary parameter is out
the limits.
27 EX-VCC Power
External DC Voltage.
Supplies voltage for DC isolation input signal (/TRIG8V,
/TRIG24V)
28 EX-V1 Power
External DC Voltage.
Supplies voltage for IDX and EOM signal pull-up
resistance.
30 /IDX Output
“End of analog measurement” signal.
This signal is output when analog measurement is
complete. This means that once the handler has received
this signal, the next DUT can be connected to the
UNKNOWN terminal. However, measurement data are
not available until the /EOM signal is output.
31 /EOM Output
“End of measurement cycle” signal.
When this signal is output, the measurement data and
sorting results are available.
32 EX-COM2 Power Common signals for external DC current EX-V2.
33
34
EX-COM Power
Common signal for external DC current EX-VCC
35
36
EX-COM1 Power
Common signals for external DC current EX-V1.
8.2 PowerRating
Input/Output device Logic Electrical requirements
OUTPUT Corrector out with
pull-up resistance
Negative logic 35VDC
50mADC max
INPUT Negative logic 50mADC max
EXT.DCV DC voltage input 35VDC max
