33[Setup] Ke
y
NOTE
Auto LCZ Function cannot judge complex components, please do not rely entirely on
this function to measure.
To set up the Auto LCZ Function
Step 1. Press the [Setup] key
Step 2. Use the cursor key to select [BIAS] field
Step 3. Use the soft keys to turn on/off the Auto LCZ Function.
Soft key Function
OFF Turn off the Auto LCZ Function
ON Turn on the Auto LCZ Function.
When Auto LCZ Function is set to ON, “AUTO-LCZ” will
display on [FUNC] field.
NOTE The Auto LCZ Function will be turned off after you set the measurement function.
5.1.5 Monitor1andMonitor2[MON1][MON2]
The AT281x can monitor the other two parameters.
NOTE:
Additional monitoring parameters do not increase the instrument measurement time.
Monitor parameter display in <MEAS DISPLAY> page only.
Procedure for setting monitor parameters (monitor 1 and monitor 2)
Step 1. Press the [Setup] key
Step 2. Use the cursor key to select [MON 1] or [MON 2] field
Step 3. Use the soft keys to select DC bias voltage.
Soft key Function
OFF Turn off the monitor
Z Absolute value of impedance
D Dissipation factor
Q Quality factor(=1/D)
r
Phase radian
d
Phase angle
R
Resistance (=Rs)
X Reactance
G Conductance
Y Absolute value of admittance
Vac Test signal Voltage
Iac Test signal Current
Absolute deviation value
%
Relative deviation value
5.2 <CORRECTION>Page
When you press [Setup] key and [CORRECTION] soft key, the <CORRECTION> page
appears.
