75Command Reference
Command Syntax
APERture {SLOW,MED1,MED2,FAST}
APERture <value>
Parameter
Where,
SLOW Set test speed to slow
MED1 Set test speed to medium (level 1)
MED2 Set test speed to medium (level 2)
FAST Set test speed to fast
<value> NR1(0 to 256): Averaging rate (0=OFF=1)
Example
SEND> APER FAST<NL>
SEND> APER 10<NL>
11.10.1 APERture:RATE?
The APERture:RATE? query returns the current integration time.
Query Syntax
APER:RATE?
Query Response
SLOW
Example
SEND> APER:RATE?<NL>
RET> slow<NL>
11.10.2 APERture:AVG?
The APERture:AVG? query returns the averaging rate settings.
Query Syntax
APER:AVG?
Query Response
<NR1>
Integer (0 to 256)
Example
SEND> APER:AVG?<NL>
RET> 0<NL>
11.11 FETChSubsystem
The FETCh subsystem command group is a sensor-only command which retrieves the
measurement data taken by measurement(s) initiated by a trigger, and places the data
into the output buffer.
Figure11‐7 FETChSubsystemCommandTree
