21[Meas] Key
R-Q R-X
Z-r Z-d
Monitor parameters
Table4‐2 Monitorparameters
Z D Q
r d
R X
G B Y
Vac Iac
Δ Δ%
Measurement and Monitor parameter descriptions
Parameter Description
Cs Capacitance value measured using the series equivalent circuit model
Cp Capacitance value measured using the parallel equivalent circuit model
Ls Inductance value measured using the series equivalent circuit model
Lp Inductance value measured using the parallel equivalent circuit model
Rs Equivalent series resistance measured using the series equivalent circuit model
(ESR)
Rp Equivalent parallel resistance measured using the parallel equivalent circuit
model
Z Absolute value of impedance
Y Absolute value of admittance
G Conductance
B Sustenance
R
Resistance (=Rs)
X Reactance
D Dissipation factor
Q Quality factor(=1/D)
r
Phase radian
d
Phase angle
Vac Test signal Voltage
Iac Test signal Current
Δ Absolute deviation value
Δ% Relative deviation value
Procedure for setting the measurement function [FUNC]
Step 1. Press the [Meas] key
Step 2. Press the <MEAS DISPLAY> soft key
Step 3. Use the cursor key to select [FUNC] field
Step 4. Use the soft keys to select measurement function.
4.1.2 ImpedanceRange[RANGE]
