AT2818/2816A/2816B/2817A/2817/810A User's Guide
DECR -
Table4‐8 AT2818’sTestFrequencythatcanbesetusingINCR++/DECR‐‐
INCR++/DECR--
10Hz 50Hz 60Hz 100Hz 120Hz
1kHz 10kHz 20kHz 40kHz 50kHz
100kHz 200kHz 250kHz 300kHz
Table4‐9 AT2816X’sTestFrequencythatcanbesetusingINCR++/DECR‐‐
INCR++/DECR--
50Hz 60Hz 100Hz 120Hz
1kHz 10kHz 20kHz 40kHz 50kHz
100kHz 200kHz
Table4‐10 AT2818’sTestFrequencythatcanbesetusingINCR+/DECR‐
INCR+/DECR- (Hz)
10 12 15 20 25 30 40 50 60 80
100 120 150 200 250 300 400 500 600 800
1k 1.2k 1.5k 2k 2.5k 3k 4k 5k 6k 8k
10k 12k 15k 20k 25k 30k 40k 50k 60k 80k
100k 120k 150k 200k 250k 300k
Table4‐11 AT2816X’sTestFrequencythatcanbesetusingINCR+/DECR‐
INCR+/DECR- (Hz)
50 60 80
100 120 150 200 250 300 400 500 600 800
1k 1.2k 1.5k 2k 2.5k 3k 4k 5k 6k 8k
10k 12k 15k 20k 25k 30k 40k 50k 60k 80k
100k 120k 150k 200k
Table4‐12 AT2817A’sTestFrequencythatcanbesetusingINCR+/DECR‐
INCR+/DECR- (Hz)
50Hz 60Hz 100Hz 120Hz
200Hz 400Hz 500Hz 1kHz
2kHz 4kHz 5kHz 10kHz
20kHz 40kHz 50kHz 100kHz
Table4‐13 AT2817’sTestFrequencythatcanbesetusingINCR+/DECR‐
INCR+/DECR- (Hz)
50Hz 60Hz 100Hz 120Hz
1kHz 10kHz 20kHz 40kHz
50kHz 100kHz
Table4‐14 AT810A’sTestFrequencythatcanbesetusingINCR++/DECR‐‐
INCR++/DECR--
10Hz 50Hz 60Hz 100Hz 120Hz
1kHz 10kHz 20kHz
4.1.4 TriggerMode[TRIG]
AT281x supports four trigger modes: INT (internal), EXT (external), MAN (manual)
