56
AT2818/2816A/2816B/2817A/2817/810A User's Guide
9. Examples
This chapter covers basic measurement procedures as well as basic L, C, and R
measurement theory. It also offers various measurement hints. After the descriptions of
basic measurement procedures, practical measurement examples are shown using AT281x.
9.1 BasicMeasurementProcedure
The following flow chart shows the basic procedures used to measure the impedance of
capacitors, inductors, resistors, and other components. Follow the procedures to perform
impedance measurements while referring to the items noted to the right side of each
step.
Figure9‐1 BasicMeasurementProcedure
