AT2818/2816A/2816B/2817A/2817/810A User's Guide
11.12.3 COMParator:AUX
The COMParator:AUX command sets the auxiliary BIN counting function of the
comparator to ON or OFF.
Command Syntax
COMParator:AUX {ON,OFF,1,0}
Parameter
Where,{ON,OFF,1,0} is:
ON or 1 Set the AUX BIN to ON
OFF or 0 Set the AUX BIN to OFF
Example
SEND> COMP:AUX OFF<NL>
Query Syntax
COMParator:AUX?
Query Response
{on,off}
Example
SEND> COMP:AUX?<NL>
RET> on<NL>
11.12.4 COMParator:BINS
The COMParator:BINS command sets the total number of bins.
Command Syntax
COMParator:BINS <value>
Parameter
Where,{value} is:
NR1 (1 to 9)
Example
SEND> COMP:BINS 3<NL>
Query Syntax
COMParator:BINS?
Query Response
<NR1> (1 to 9)
Example
SEND> COMP:BINS?<NL>
RET> 3<NL>
11.12.5 COMParator:TOLerance:NOMinal
The COMParator:TOLerance:NOMinal command sets the nominal value for the
tolerance mode of the comparator function.
Command Syntax
COMParator:TOLerance:NOMinal <value>
Parameter
Where,<value> is:
NR1, NR2 or NR3
A suffix multiplier can be used with this command. But the suffix unit F//H can’t be
used.
Example
SEND> COMP:TOL:NOM 100N<NL>
SEND> COMP:TOL:NOM 1E-6<NL>
Query Syntax
COMParator:TOLerance:NOMinal?
Query Response
<NR3>
Example
SEND> COMP:TOL:NOM?<NL>
RET> 1.000000e-06<NL>
11.12.6 COMParator:TOLerance:BIN
The COMParator:TOLerance:BIN command sets the low/high limit values of each BIN
for the comparator function tolerance mode.
Command Syntax
COMParator:TOLerance:BIN <n>,<low limit>,<high limit>
Parameter
Where,<n>,<low limit>,<high limit> is:
n NR1 (1 to 9): Bin number
low limit NR1,NR2 or NR3: low limit value
