AT2818/2816A/2816B/2817A/2817/810A User's Guide
12. Specification
This chapter describes the specifications and supplemental performance characteristics
of the AT281x:
Specifications
Dimension
Accuracy is defined as meeting all of the following conditions.
Temperature: 23℃±5℃
Humidity: 65% R.H.
Zeroing: Open and Short Correction
Warm up time is 30 min or more.
Rate: Slow
A 1-year calibration cycle
Test frequency accuracy: 0.02%
Test signal level: 10%
Basic Accuracy:
AT2818/AT2816A/AT2817A/AT2817/810A:0.05%
AT2816B:0.1%
12.1 GeneralSpecification
Display: True color TFT-LCD, Size: 3.5”
Test Function: Cs-Rs, Cs-D, Cp-Rp, Cp-D, Lp-Rp, Lp-Q, Ls-Rs, Ls-Q, G-B, Rs-Q, Z-r, Z-d.
AT2818: 10Hz~300kHz
Frequency range(F) Resolution
10.0000Hz F 99.9999Hz
0.0001Hz
100.0000Hz F 999.999Hz
0.001Hz
1.00000kHz F 9.99999kHz
0.01Hz
10.0000kHz F 99.9999kHz
0.1Hz
100.000kHz F 300.000kHz
1Hz
AT2816A: 50Hz~200kHz
Frequency range(F) Resolution
10.0000Hz F 99.9999Hz
0.0001Hz
100.0000Hz F 999.999Hz
0.001Hz
