89Specification
1.00000kHz  F  9.99999kHz
0.01Hz
10.0000kHz  F  99.9999kHz
0.1Hz
100.000kHz  F  200.000kHz
1Hz
AT2816B: [37 Points]
50, 60, 80, 100, 120, 150, 200, 250, 300,400, 500, 600, 800,
1e3, 1.2e3, 1.5e3, 2e3, 2.5e3, 3e3, 4e3, 5e3, 6e3, 8e3,
10e3, 12e3, 15e3, 20e3, 25e3, 30e3, 40e3, 50e3, 60e3, 80e3,
100e3, 120e3, 150e3, 200e3
AT2817A : [16 Points]
50, 60, 100, 120, 200, 400, 500, 1e3, 2e3, 4e3, 5e3, 10e3, 20e3, 40e3, 50e3, 100e3
AT2817 : [10 Points]
50, 60, 100, 120, 1e3, 10e3, 20e3, 40e3, 50e3, 100e3
AT810A: 10Hz～20kHz
Frequency range(F) Resolution
10.0000Hz  F  99.9999Hz
0.0001Hz
100.0000Hz  F  999.999Hz
0.001Hz
1.00000kHz  F  9.99999kHz
0.01Hz
10.0000kHz  F  20.0000kHz
0.1Hz
Measurement Range
AT2818 AT2816A AT2816B AT2817A
Parameter Measurement Range
L
0.00001H ～ 9999.99H
C
0.00001pF ～ 9999.99mF
R、X、Z 0.00001Ω ～ 99.9999M
B、G 0.01nS ～ 999.999S
D
0.00001 ～ 9.99999
Q
0.00001 ～ 99999.9
θd -179.999°～179.999°
θr -3.14159 ～ 3.14159
AT2817
Parameter Measurement Range
L
0.0001nH ～ 9999.9H
