Attribute Acceptance criteria Example
6-dye: blue-green-
yellow-red-purple-
orange
Order of the peaks in
the r
aw data profile
from left to right
Sequencing (matrix
standard only):
4-dye: red-yellow-
blue-green
Order of the peaks in
the raw data profile
from left to right
Fragment analysis:
• 4-dye: red-
yellow-green-
blue
• 5-dye: orange-
red-yellow-
green-blue
Extraneous peaks in
the r
aw data profile
(intensity vs scan)
None
Note: The E5 profile
may include
extraneous peaks
outside the matrix
peak region, which
can be ignored.
Chapter 8 Calibrate the instrument
Perform spectral calibration for sequencing and fragment analysis
8
3730xl DNA Analyzer with 3730xl Data Collection Software 5 User Guide
107
