Operation
5-3
5
P/N 6525032M1 - X6
Starting procedure [4.1.c]
WARNING: The engine may be started only in
the conditions given here under. Otherwise,
please contact your Argo Tractors Dealer.
1. Make sure the Master Disconnect Switch is in the ON
position (turned clockwise).
2. Check that the reverse shuttle and gearshift levers are
in neutral.
Turn the rear PTO control switch off.
For tractors with front PTO, disengage the control (switch).
3. Check that the levers of the auxiliary control valves are
in neutral and that the hitch control position matches
the implement position, that is completely lowered.
4. Turn the ignition key on the ON position, wait a few
seconds, then turn the key on the start position. Thus
the electronic control systems are activated and are
able to communicate with each other. The system will
perform a Lamp Check. All the lamps in the cab will
light for a few seconds. After a few seconds, only the
lamps involved in the starting phase will stay on.
5. Shift the FNR lever to disengage the Park Lock (if
provided).
TURBO ENGINE: Allow the engine to run for a few sec-
onds with the starter motor to allow the turbo compressor
to be lubricated.
OPERATION
WARNING: Carefully read the starting instruc-
tions before starting the tractor.
WARNING: Always take into account the use
of the machine and the work place. Take
every precaution, specially if there is a high
risk of fire.
WARNING: DO NOT start the tractor from the
ground. Only start the tractor when you are
sitting in the driving seat.
WARNING: DO NOT start the tractor if the
bonnet is open or the guards are removed.
WARNING: The operator must always seat in
his/her place when driving the tractor both in
the field and on roads. DO NOT stand up from
your seat when the tractor is moving.
