5-66
Operation
X6 - P/N 6525032M1
REAR THREE-POINT HITCH
The three-point hitch system gives position control and load control of soil engaging implements.
According to its tailored specifications, the tractor may be suited to Cat. II implements, compliant with SAE-ASAE stand-
ard dimensions:
All models
IMPLEMENT Category II
Diameters of hitch balls 56 mm
Diameters of hitch pins 37mm
WARNING: Before connecting or using imple-
ments and trailers, ALWAYS read thoroughly
and follow the instructions of the operator's
manual provided by the manufacturer.
WARNING: Never work under an implement
that is kept raised only by the hydraulic hitch,
but always secure it with a suitable support.
Engage the first gear, engage the parking
brake, turn the engine off and remove the
ignition key.
When using the three point hitch ensure there is sufficient
clearance between the rear tyres and the lower links by
adjusting the stabilizers and/or tread positions.
The top and lower links must be adjusted correctly so
that the implement can work at the required depth and
that the lower links are free to move up and down with
the shape of the ground.
After making any adjustments, carefully raise the imple-
ment to make sure there is clearance between the tractor
and implement.
Make sure tyre pressures, wheel equipment and ballasting
are correct before making hitch adjustments.
WARNING: Extreme care must be exercised
when adjusting and checking the hitch and
control linkage when the engine is running
and when linkage is under hydraulic or me-
chanical load. Study the linkage and hitch
travel, keep hands, arms, legs and feet out of
the travel arc of the hitch and linkage.
Make sure that no persons are in the danger
area.
