9-8
Specifications
X6 - P/N 6525032M1
Brakes
Rear brakes
Multiplate oil-cooled brakes mounted on rear differential
transaxles.
Number of friction discs:................. 2 (1 each side)
Friction material ....................................................... N670
Hydraulic braking control by means of two pedals located
at driver's right. The two pedals can be coupled by a
locking device to provide simultaneous braking action
on both sides.
Parking brake controlled by a hand lever and independent
control wire, by direct control on a multiplate oil-cooled
brake (6 plates) mounted on the 4WD shaft.
Plates in sintered bronze.
Hydraulic trailer brake mounted on request.
Air trailer brake mounted on request.
Front brakes
(setup with suspended axle)
Multidisc oil-cooled brakes mounted on front differential
transaxles.
Number of friction discs:
Sprung axle ................................................ 1 (each side)
Friction material ..........................................resin-graphite
Hydraulic IBS-Integral Braking System control to ensure
simultaneous braking with rear brakes when the brake
pedals are locked together with the locking device.
Front axle
In spheroidal cast iron, pivoting at the centre within two
supports
Front drive engaging control, electro-hydraulic by hydraulic
clutch.
Spring-on - Pressure off type.
Drive shaft mounted on the longitudinal axis
• without universal joints (setup with rigid axle)
• with one universal joint (setup with suspended axle)
Transmission via central differential and epicyclic final
drives in wheel hubs.
Max. steering angle ....................................................55°
'Twin-Lock' diff lock with electro-hydraulic control as
standard. Diff lock is engaged simultaneously with rear
diff lock. The diff lock is disengaged by means of the
brake pedals.
Interflange: ...............................................................1887
Distance between spindles: ............................ 1,530mm
Reduction ratios (setup with rigid axle):
Bevel gear pair .............................................8/31=3,875
Epicyclic final drives ................................15/15+63=5,2
Total reduction ..................................................................
........................................................................................7
20,15
Reduction ratios (setup with suspended axle):
Bevel gear pair .............................................9/31=3,444
Epicyclic final drives ...............................................6,000
Total reduction ..................................................................
........................................................................................7
20,666
