Controls - Cab
3-15
3
P/N 6525032M1 - X6
Operator present sensor
The seat cushion acts as a switch.
WARNING: Do not tamper with this compo-
nent in any way.
WARNING: if the tractor is not correctly used,
the operator is informed by the sound of a
buzzer and a warning symbol on the instru-
ment cluster.
For a correct use, the operator must be seated in the
driver's place. As soon as there is no load on the seat given
by the operator's weight, a buzzer sounds and a warning
symbol (1-Fig.3-33) is shown on the instrument cluster.
Fig. 3-33
1
In all versions of this tractor, the buzzer sounds each time
the operator leaves the driver's seat while the engine is
running whiteout engaging the parking brake and putting
the gearshift lever in neutral.
Whenever the operator leaves the driver's seat with the
engine running and the tractor not moving, the hydraulic
clutches of forward and reverse are disabled. If the tractor
is on the move, the system inhibits the same clutches as
soon as the neutral position of the reverse shuttle lever
is sensed. In this case, the transmission goes automati-
cally to Neutral.
The operator must then return to his/her seat and the
reverse shuttle shifted to Neutral in order to get the trac-
tor started again.
Fig. 3-32
