Maintenance
7-27
7
P/N 6525032M1 - X6
STEP 10A
Dry air filter discharge valve
WARNING: Always use the specific PPE for the opera-
tion concerned.
WARNING: Beware of burns caused by hot water and
engine parts.
Everyday or whenever required by ambient conditions,
clean the dry air filter by pressing on the rubber end (2)
to remove any dust or dirt.
WARNING: If you need to open the bonnet, follow the
procedure indicated under "How to open the bonnet".
1. Dry air filter
2. Exhaust valve
3. Primary (outer) filter element
4. Secondary (inner) filter element
IMPORTANT: ONLY use approved air filters, as these
filters are specifically designed to provide superior engine
protection.
NOTE: The discharge valve is not available if an automatic
dust ejector is fitted.
