5-48
Operation
X6 - P/N 6525032M1
Hook/clevis change over
(if fitted, on request on certain markets)
STEP 1
Lower the auto hitch half way.
IMPORTANT: After lowering the auto hitch, stop the
engine, and engage the parking brake before leaving
the tractor.
STEP 2
1
Remove the hook/clevis locating pins (1).
STEP 3
Remove the hook or clevis. Install the hook or clevis in
the storage bracket located at the front of the tractor on
the left hand side.
Install the hook or clevis. Install the lock pins.
Retract the assembly and raise auto hitch until locked,
then lower onto latches.
NOTE: Make sure local regulations are followed when
towing implements/trailers. Specific speed limits are
prescribed when using drawbars or tie down brackets
on public roads. Moreover, the road circulation codes of
some countries prescribe that suitable brakes are installed
on vehicles that are towed on public roads.
Before circulation on public roads, be sure your tractor
complies with ALL the legal requirements.
