Maintenance
7-43
7
P/N 6525032M1 - X6
Locking devices for automatic hitch-
ing of the Pick Up Hitch
(if equipped, according to market)
Locking latches and rear pivots, 2 points.
1. The hitch should be carefully cleaned every 100 hour
operation, and the moving parts (also inner slide rails)
should be greased to avoid corrosion.
2. Make sure that all moving parts move freely and oper-
ate correctly.
NOTE: In heavy duty operating conditions, the hitch could
require a more frequent greasing to ensure it operates
correctly.
Trailer hitch slide rails and hitch cou-
pling operating parts
(if equipped).
Hitch clevis, 1 point (depending on model)
The hitch should be thoroughly cleaned and all moving
parts, including the inner slide rails, should be greased to
protect from corrosion.
Make sure that all moving parts move freely and operate
correctly.
Pin grease nipple, 1 point (depending on hitch model)
