3-18
Controls - Cab
X6 - P/N 6525032M1
Fig. 3-36
3. Battery master disconnect switch
(Fig. 3-34, 3-36)
The master disconnect switch (3) disconnects the battery
from the tractor electric system.
The master disconnect switch (3) can only be activated
with the ignition key in the OFF position.
WARNING: When the engine is running, the battery
cannot be disconnected in any way.
This switch has two positions:
● Position A: battery connected, all systems are supplied
● Position B: battery disconnected, only the instrument
cluster, the courtesy light in the cab and the radio
memories are powered.
For a correct use of the battery disconnector switch,
refer to the "Operation" section, "Battery disconnector
switch" chapter.
