TD 93021US
17 July 2017 / Ver
. PF3
109
Installation Guide
teleCARE IP
Next connect the NIRD room disp
lay to the NISP and plug in the room bus connector
.
Figur
e 148. Connecting the NIRD to the NISP and connecting the room bus
Refer to
6.16.1, Room
Bus Electrical Connections on page 104
for full details.
Next, snap fit the room display to the backplate.
Figur
e 149. Mounting the NIRD on the backplate
113
115
