NUREP External Power Supply Connection
Connect the supplied 5VDC Class II power adapter to the wireless repeater.
Figure 184. Connect the external power supply.
NUREP Battery Placement (Optional)
It is possible to place two batteries as backup power in case the mains power fails. Place the two AA
type 1.5V alkaline batteries according the image below, observe polarity.
Figure 185. Insert the batteries
