TD 93021US
17 July 2017 / Ver. PF3 137
Installation Guide
teleCARE IP
NILF range test
To perform an LF range test the following equipment is required:
• An NILF location beacon.
• An NITX or NIFX with LF functionality that is set to “LF test” mode.
Note: For detailed information on how to put the NITX or NIFX in LF test mode, refer to
“Appendix - Wireless Planning Considerations” of the teleCARE IP Configuration Manual
“TD 93019US”.
To set up the equipment for the LF range test, mount the NILF at the required location and insert the
batteries.
When the wireless module (NITX or NIFX) is in range of the LF field of the NILF the LED will flash shortly
once every second for as long as it is in range of the LF field.
1 second interval between flashes
