Pset STwrench User Guide
104 (326) 9836 4134 01 Edition 2.9
First line of yellow LEDs
Torque over 1
st
percentage.
Second row of yellow LEDs
Torque over 2
sd
percentage.
Torque over 3
rd
percentage.
NOTE: The three rows of LEDs are all activated if the torque goes over the Max. Torque value (normally set
higher than the 3
rd
percentage value).
The beep emitted by the buzzer starts when the torque goes over the Cycle Start
value; it increases its signal when the 1
st
percentage, the 2
nd
percentage, the 3
rd
percentage, and the Max torque are reached.
At the end of the tightening operation, two more beeps inform the operator of the
end of the operation, and if the final result is in the red area, the buzzer signal
stays steadily ON.
Activated together with the third row of LEDs, and remains active until the
torque applied to the wrench is released.
