Identifier STwrench User Guide
160 (326) 9836 4134 01 Edition 2.9
10 STwrench Settings
10.1 Settings Menu on the STwrench
The Settings menu on the wrench display is active only if enabled. See STwrench Controller Setup to
enable / disable this menu. The Diagnostic menu is covered in the Troubleshooting Guide chapter of this
manual. See Appendix C - STwrench Factory Settings for the default configuration.
10.1.1 Wrench display language
To set the wrench display language, select Wrench Setup → Language from the STwrench main menu:
Select the language and confirm with the OK button on the wrench keyboard.
It is also possible to set the language through ToolsTalk BLM. See the chapter Setting the STwrench
display language).
10.1.2 CCA procedure
When an extension is used, the proper torque and angle correction coefficients must be set in the TAG.
From this menu, it is possible to enter the Torque Correction Coefficient manually and execute the
procedure to calculate the Angle Correction Coefficient (CCA). See Appendix A – Calculating Torque and
Angle Correction Coefficients for more information.
NOTE: The CCA Procedure function is available from STwrench firmware 2.3a.
shown if the smartHEAD has
been not calibrated in all its
parameters.
