STwrench User Guide System overview
9836 4134 01 Edition 2.9 47 (326)
IRC-W, three channels occupying the 2.4GHz ISM band.
2.4.6.1 QAT IRC-W radio module
The IRC-W Dual Band radio module allows the interface between the STwrench and
ToolsNet, Power Focus, QATnode, and API.
To install the IRC-W module in the wrench, turn off the wrench, remove the cover and insert the IRC-W
module (tighten the two screws with your fingers).
After having installed the module in the unit, you need to set radio parameters via ToolsTalk BLM.
