Atlas Copco STwrench User Manual

STwrench User Guide Pset
9836 4134 01 Edition 2.9 135 (326)
6.7.2.4 Residual Torque/Peak
This strategy evaluates the residual torque on a joint as the peak torque necessary to rotate the screw
further.
With this strategy the breakaway point is not detected automatically. Therefore, this is a less objective
method of evaluating residual torque; it may be used in cases in which the residual torque/time or
torque/angle methods cannot be performed.
Simply specify the torque limits to have a OK result.
If the Target Angle is not specified, the angle result is marked as Not Applicable.
If you specify a Target Angle value, the residual torque result is measured at the specified angle (starting
from the Start final angle) instead of the peak torque:
Min Torque
Max Torque
Torque Peak
Min Torque
Max Torque
Start final angle
Cycle start
Cycle start
