STwrench Settings STwrench User Guide
166 (326) 9836 4134 01 Edition 2.9
10.2.1.14 Enabling STwrench automatic shutdown
Automatic shutdown timeout
Sets the timeout for automatic shutdown when the STwrench is
switched on but not being used and not connected to ToolsTalk BLM.
Leave it set to zero to disable automatic shutdown.
NOTE: When the STwrench works in Power Focus mode, this
parameter is not considered and is substituted with the timeout
specified inside Power Focus. If the STwrench is connected to Power
Focus with the SL Cable, the automatic shutdown function is ignored
and the wrench always on.
10.2.1.15 Enabling STwrench general display timeout
General display timeout
This option defines how long the display shows the information
before going onto the next screen; it is applied in the following cases:
- Result screen if end-fitting tool is removed (if TAG is enabled).
- Warning battery.
- Result screen before lock (for QATnode).
- Result of a Pset with auto delete (in case of batch, only for the last
result).
- Last result of a Pset in the batch of a Job.
- Batch result of a Job.
The valid value of the parameter is 0.0 to 6.0 seconds. The value 0.0
means no timeout. In that case, the OK button must be pressed on the
wrench keyboard in order to proceed to the next screen.
NOTE: The default value is 1.5. It is not recommended to set the
value to low.
10.2.1.16 Setting the source for Pset/Multistage/Job selection
When the STwrench is working with the QATnode, these two parameters are overridden by those defined
in the STwrench QATnode settings. See the chapter QATnode and STwrench Settings for more
information.
This setting defines the way in which you select a Pset /Multistage/Job.
Keyboard: Manual Pset/Multistage selection from the Prog. Mode
menu on the
wrench display.
