Pset STwrench User Guide
94 (326) 9836 4134 01 Edition 2.9
NOTE: If the Batch count is disabled, the Batch status in the tightening results
is always OK.
By enabling the Batch count and setting the Batch size to 1, The Batch result
status will only be OK if the Pset shows OK.
If the Batch size is greater than 1, the Batch result is OK only if all the Psets
show OK.
If enabled, at the end of the batch the wrench freezes the display; to exit the
menu, the operator must press the OK button.
If not enabled, when the batch is completed, a new batch will start again.
results
Maximum number of Pset with Not OK result.
Maximum value: 9
For instance, if this parameter is set to 2, at the second Not OK result during the
batch execution, the batch execution stops and the following error message is
shown on the wrench display:
This parameter is active only if the batch increment condition is set to OK in
the controller configuration.
6.5 Options
required
If enabled, the Pset execution checks that the specified end-fitting tool is
inserted in the wrench head.
Note that this function performs only a check, and does not start the Pset
automatically; to use the end-fitting tool recognition function to automatically
select Pset/Multistage, see the Setting the source for Pset/Multistage/Job
selection chapter. When this function is used, this flag does not have any
effect.
