STwrench User Guide STwrench Settings
9836 4134 01 Edition 2.9 181 (326)
10.3.1 Information
This window provides some information about the smartHEAD currently on the STwrench:
Serial number
Serial number of the STwrench smartHEAD.
Calibration value
Calibration value of the smartHEAD currently installed on the wrench.
Cell sensitivity (gain)
Transducer gain (set to 2, or 0.8, or 0.59).
Span
Value set by factory to 100%, or 120%, or 150%, or 200%.
This value, multiplied by the Calibration value, gives the Wrench capacity.
Min. Load
Minimum torque value readable from the smartHEAD installed on the
STwrench.
