Pset STwrench User Guide
134 (326) 9836 4134 01 Edition 2.9
For instance, a bolt tightened to 100 Nm and using a STwrench with 150 Nm smartHEAD to detect the
residual point could be a proper setting:
In the wrench torque/angle trace, the
torque is left at zero until the torque
reaches the Start Final Angle (50
Nm). The circle on the trace indicates
the detected residual point.
If the residual point falls outside the
torque limits, it is marked as Not OK
with
.
Cycle start
Break away
