Working with Power Focus STwrench User Guide
218 (326) 9836 4134 01 Edition 2.9
3. At the end of the zero adjustment, the wrench goes into pairing mode
4. Start the pairing procedure on Power Focus
5. Wait for the end of the procedure (make sure that it ends without error)
The STwrench is now working in the Power Focus mode.
Ensure that Power Focus is also set to work via an IRC-B connection.
NOTE: To restore the normal working mode, perform the same procedure, pressing the wrench
buttons in the reverse sequence (BARCODE, RIGHT and UP).
NOTE: The pairing procedure can also be performed from ToolsTalk BLM. See Power Focus
settings for more information.
NOTE: When the STwrench is connected to the ToolsTalk BLM via the USB cable, the
connection with Power Focus is not active. After completing the wrench settings and/or
programming, disconnect the USB cable to activate the connection to Power Focus.
