W
orking with
Tor
que Supervisor
STwrench Us
er G
uide
248
(
326
)
9836 4134 01 Edition 2.9
Once all of the set
t
ings are done, en
able the connection to API
and click on
St
ore
to save:
Data rate
Select the d
ata rate. A slow
er value may
help when the com
munication
is
not
hi
gh
-
perform
ance.
Power mode
Th
e
Slee
p
mode is recommended for lower power consumption.
Roaming th
reshold
Select the threshold under
which the STwrench
w
ill
sear
ch
for
a new acc
ess
point to connect
thr
ou
gh
.
Enable connection
Click on
Store
247
