STwrench User Guide Working with the QATnode
9836 4134 01 Edition 2.9 285 (326)
STwrench; it is active until the end of the tightening. Note that
if the input status does not change and the same tightening
program is executed again, this output is not activated again; to
reactivate it, a different tightening program must be uploaded,
or the same tightening program must be selected again after
first passing through an “idle” status.
- To next tight: The output is activated at the end of the
tightening program, and it remains active until the next
tightening program is completed. For an IRDA connection, this
means that the output is updated with the new results when the
wrench is put back on the QATnode after the new tightening
operation.
For the output “Program Loaded OK”, the output is activated
immediately when the program is selected on the STwrench,
and it remains active until the end of the current tightening
operation.
- Time: Allows you to define for how long the output must
remain active.
- Tracking event: Outputs like Tool Connected or ToolsNet
Connected are not related to the ongoing tightening operation;
therefore, the output keeps tracking the event in real time.
Setting the Relay timer to Time specifies how long the output
will remain active before timing out.
Once the configuration is done, click on Store to save.
