AudioCodes MediaPack MP-11 Series User Manual

Version 7.2 1177 Mediant 1000B Gateway & E-SBC
User's Manual 62. Configuration Parameters Reference
Parameter Description
[EnergyDetectorThreshold]
Actual Threshold = -44 dBm + (EnergyDetectorThreshold * 6)
The valid value range is 0 to 7. The default is 3 (i.e., -26 dBm).
Pattern Detection Parameters
Note: For an overview on the pattern detector feature for TDM tunneling, see DSP Pattern Detector
on page 457.
Enable Pattern Detector
[EnablePatternDetector]
Enables the Pattern Detector (PD) feature.
 [0] Disable (default)
 [1] Enable
[PDPattern] Defines the patterns that can be detected by the Pattern
Detector.
The valid range is 0 to 0xFF.
Note: For the parameter to take effect, a device reset is
required.
[PDThreshold] Defines the number of consecutive patterns to trigger the
pattern detection event.
The valid range is 0 to 31. The default is 5.
Note: For the parameter to take effect, a device reset is
required.
62.13 Services
62.13.1 RADIUS and LDAP Parameters
62.13.1.1 General Parameters
The general RADIUS and LDAP parameters are described in the table below.
Table 62-74: General RADIUS and LDAP Parameters
Parameter Description
Use Local Users Database
configure system > mgmt-auth
> use-local-users-db
[MgmtUseLocalUsersDatabase]
Defines when the device uses the Local Users table or an
LDAP/RADIUS server for authenticating the login credentials
(username-password) of users when logging into the device's
management interface (e.g., Web or CLI).
 [0] When No Auth Server Defined = (Default) The device
authenticates the users using the Local Users table in the
following scenarios:

If no LDAP/RADIUS server is configured.

If an LDAP/RADIUS server is configured, but connectivity
with the server is down. If there is connectivity with the
server, the device uses the server to authenticate the user.
 [1] Always = The device first attempts to authenticate the user
using the Local Users table. If no user is found (based on the
username-password combination), it attempts to authenticate
the user using the LDAP/RADIUS server.
Behavior upon Authentication
Defines the device's response when a connection timeout occurs

AudioCodes MediaPack MP-11 Series Specifications

General

Brand	AudioCodes
Model	MediaPack MP-11 Series
Category	Gateway
Language	English
