User's Manual 806 Document #: LTRT-27045
Mediant 1000B Gateway & E-SBC
48.2 Viewing History Alarms
You can view all SNMP alarms, in the Web interface's Alarms History table, that have been
raised (active alarms) as well as cleared (resolved). One of the benefits of this is that you
can view alarms that may have been raised and then cleared on a continuous basis. For
example, such an alarm may be raised due to an Ethernet cable that is not securely
attached to the device's Ethernet port, causing the Ethernet link to be sometimes up and
sometimes down. This alarm would not be listed in the Active Alarms table due to it being
cleared. The Alarms History table displays both the cleared alarm and the alarm for which it
was cleared adjacent to one another, as shown in the figure below for alarms #9 and #10.
To configure the maximum number of alarms that can be displayed in the table, use the
AlarmHistoryTableMaxSize ini file parameter. If the maximum is reached and a new alarm
is added to the table, the oldest alarm is removed from the table to accommodate the new
alarm.
Note:
• The alarms in the table are deleted upon a device reset.
• For more information on SNMP alarms, refer to the SNMP Reference Guide
document.
To view history alarms:
Open the Alarms History table (Monitor menu > Monitor tab > Summary folder >
Alarms History).
Figure 48-1: Viewing Alarms History Table
Table 48-2: Alarms History Table Description
Field Description
Sequential Number
The number of the alarm. The alarms are numbered sequentially as they
are raised by the device. The numbering resets to 1 immediately after a
device reset (i.e., the first alarm raised after a reset is assigned the number
#1).
Severity
Severity level of the alarm:
Critical (red)
Major (orange)
Minor (yellow)
Cleared (green)
Source
Component of the device from which the alarm was raised.
Description
Brief description of the alarm.
