User's Manual 238 Document #: LTRT-27045
Mediant 1000B Gateway & E-SBC
To configure an LDAP base path per LDAP server:
1. Open the LDAP Servers table (Setup menu > IP Network tab > RADIUS & LDAP
folder > LDAP Servers).
2. In the table, select the row of the LDAP server for which you want to configure DN
base paths, and then click the LDAP Servers Search Based DNs link located below
the table; the LDAP Server Search Base DN table opens.
3. Click New; the following dialog box appears:
Figure 15-20: LDAP Search Base DN Table - Add Dialog Box
4. Configure an LDAP DN base path according to the parameters described in the table
below.
5. Click Apply, and then save your settings to flash memory.
Table 15-9: LDAP Server Search Base DN Table Parameter Descriptions
Parameter Description
Index
set internal-index
[LdapServersSearchDNs_Index]
Defines an index number for the new table row.
Note: Each row must be configured with a unique index.
Base DN
set base-path
[LdapServersSearchDNs_Base_Path]
Defines the full path (DN) to the objects in the AD where the
query is done.
The valid value is a string of up to 256 characters.
For ex
ample: OU=NY,DC=OCSR2,DC=local. In this example,
the DN path is defined by the LDAP names, OU
(organizational unit) and DC (domain component).
15.3.6 Configuring the LDAP Search Filter Attribute
When the LDAP-based login username-password authentication succeeds, the device
searches the LDAP server for all groups of which the user is a member. The LDAP query is
based on the following LDAP data structure:
Search base object (distinguished name or DN, e.g.,
"ou=ABC,dc=corp,dc=abc,dc=com"): The DN defines the location in the directory
from which the LDAP search begins and is configured in ''Configuring LDAP DNs
(Base Paths) per LDAP Server'' on page
237.
Filter (e.g., "(&(objectClass=person)(sAMAccountName=johnd))"): This filters the
search in the subtree to include only the login username (and excludes others). This is
configured by the 'LDAP Authentication Filter' parameter, as described in the following
procedure. You can use the dollar ($) sign to represent the username. For example,
the filter can be configured as "(sAMAccountName=$)", where if the user attempts to
log in with the username "SueM", the LDAP search is done only for the attribute
To Next Page
