Version 7.2 829 Mediant 1000B Gateway & E-SBC
User's Manual 51. Viewing VoIP Status
Field Description
Duration
Displays the duration of the call, displayed in the format hh:mm:ss,
where hh is hours, mm minutes and ss seconds. For example, 00:01:20
denotes 1 minute and 20 seconds.
Termination Reason
Displays the reason for the call being released (ended). For example,
"NORMAL_CALL_CLEAR" indicates a normal off-hook (hang up) of the
call party.
Session ID
Displays the SIP session ID of the call.
51.7 Viewing SBC CDR History
You can view historical Call Detail Records (CDR) of SBC calls in a table. History CDRs
are stored on the device’s memory. When a new CDR is generated, the device adds it to
the top of the table and all existing entries are shifted one down in the table. The table
displays the last 4,096 CDRs. If the table reaches maximum capacity of entries and a new
CDR is added, the last CDR entry is removed from the table.
Note: If the device is reset, all CDRs are deleted from memory and from the table.
To view SBC CDR history:
Web: Open the SBC CDR History table (Monitor menu > Monitor tab > VoIP Status
folder > SBC CDR History).
Figure 51-6: SBC CDR History Table
CLI:
• All CDR history:
# show voip calls history sbc
• CDR history for a specific SIP session ID:
# show voip calls history sbc <session ID>
Table 51-7: SBC CDR History Table
Field Description
Call End Time
Displays the time at which the call ended. The time is displayed in the
format, hh:mm:ss, where hh is the hour, mm the minutes and ss the
seconds (e.g., 15:06:36).
IP Group
Displays the IP Group of the leg for which the CDR was generated.
Caller
Displays the phone number (source URI user@host) of the party who
made the call.
