Version 7.2 87 Mediant 1000B Gateway & E-SBC
User's Manual 8. SNMP-Based Management
8 SNMP-Based Management
The device provides an embedded SNMP agent that lets you manage it using AudioCodes
Element Management System (EMS) or a third-party SNMP manager. The SNMP agent
supports standard and proprietary Management Information Base (MIBs). All supported
MIB files are supplied to customers as part of the release. The SNMP agent can send
unsolicited SNMP trap events to the SNMP manager.
Note:
• By default, SNMP-based management is enabled.
• For more information on the device's SNMP support such as SNMP trap alarms
and events, refer to the SNMP Reference Guide.
• For more information on AudioCodes EMS, refer to the EMS User's Manual.
8.1 Enabling SNMP
By default, SNMP is enabled. You can enable SNMP as described in the following
procedure.
 To enable SNMP:
1. Open the SNMP Community Settings page (Setup menu > Administration tab >
SNMP folder > SNMP Community Settings).
Figure 8-1: Enabling SNMP
2. Under the Misc. Settings group, from the 'Disable SNMP' drop-down list
(DisableSNMP parameter), select Yes.
3. Click Apply.
8.2 Configuring SNMP Community Strings
SNMP community strings determine the access privileges (read-only and read-write) of
SNMP clients with the device's SNMP agent. You can configure up to five read-only SNMP
community strings and up to five read-write SNMP community strings. The device's SNMP
agent accepts SNMP Get (read-only) and Set (read-write) requests only if the correct
community string is used in the request.
You can also configure a unique password-like community string used for sending SNMP
traps. The device sends the traps with the community string.
