User's Manual 140 Document #: LTRT-27045
Mediant 1000B Gateway & E-SBC
12.5.3 Networking Configuration Examples
This section provides configuration examples of networking interfaces.
12.5.3.1 One VoIP Interface for All Applications
This example describes the configuration of a single VoIP interface for all applications:
1. IP Interfaces table: Configured with a single interface for OAMP, Media and Control:
Table 12-6: Example of Single VoIP Interface in IP Interfaces table
Index
Application
Type
Interface
Mode
IP Address
Prefix
Length
Default
Gateway
Device
Name
0 OAMP,
Media &
Control
IPv4 192.168.0.2 16 192.168.0.1
1 myInterface
2. Static Routes table: Two routes are configured for directing traffic for subnet
201.201.0.0/16 to 192.168.11.10, and all traffic for subnet 202.202.0.0/16 to
192.168.11.1:
Table 12-7: Example of Static Routes Table
Destination Prefix Length Gateway
201.201.0.0 16 192.168.11.10
202.202.0.0 16 192.168.11.1
3. The NTP applications remain with their default application types.
12.5.3.2 VoIP Interface per Application Type
This example describes the configuration of three VoIP interfaces - one for each
application type:
1. IP Interfaces table: Configured with three interfaces, each for a different application
type, i.e., one for OAMP, one for Call Control, and one for RTP Media, and each with
a different VLAN ID and default gateway:
Table 12-8: Example of VoIP Interfaces per Application Type in IP Interfaces table
Index
Application
Type
Interface
Mode
IP Address
Prefix
Length
Default
Gateway
Device
Name
0 OAMP IPv4
Manual
192.168.0.2 16 192.168.0.1 1 ManagementIF
1 Control IPv4
Manual
200.200.85.14
24 200.200.85.1 200 myControlIF
2 Media IPv4
Manual
211.211.85.14
24 211.211.85.1 211 myMediaIF
2. Static Routes table: A routing rule is required to allow remote management from a
host in 176.85.49.0 / 24:
