Version 7.2 1039 Mediant 1000B Gateway & E-SBC
User's Manual 62. Configuration Parameters Reference
Parameter Description

The parameter is applicable only to analog interfaces.
Special Digit Representation
configure voip > gateway dtmf-supp-
service dtmf-and-dialing > special-
digit-rep
[UseDigitForSpecialDTMF]
Defines the representation for ‘special’ digits (‘*’ and ‘#’) that
are used for out-of-band DTMF signaling (using SIP
INFO/NOTIFY).
 [0] Special = (Default) Uses the strings ‘*’ and ‘#’.
 [1] Numeric = Uses the numerical values 10 and 11.
[ISDNKeypadMode]
Enables the device to send DTMF digits received in the
called party number from the IP side, as Keypad facility IE in
ISDN INFORMATION messages to PSTN.
 [0] Don’t send = (Default) All digits are sent as DTMF to
PSTN (i.e., not sent as Keypad).
 [1] During Call Establishment = DTMF digits after * or #
(inclusive) are sent as Keypad only during call
establishment and call disconnect. During an established
call, all digits are sent as DTMF.
 [2] Always = DTMF digits after * or # (inclusive) are
always sent as Keypad (call establishment, connect, and
disconnect).
For more information, see Interworking Keypad DTMFs for
SIP-to-ISDN Calls on page 532.
Note:
 This feature is not applicable to re-INVITE messages.
 The parameter is applicable only to digital interfaces.
62.10.3 Digit Collection and Dial Plan Parameters
The digit collection and dial plan parameters are described in the table below.
Table 62-40: Digit Collection and Dial Plan Parameters
Parameter Description
Dial Plan Index
configure voip > gateway
dtmf-supp-service dtmf-and-
dialing > dial-plan-index
[DialPlanIndex]
Defines the Dial Plan index to use in the external Dial Plan file. The
Dial Plan file is loaded to the device as a .dat file (converted using the
DConvert utility). The Dial Plan index can be defined globally or per
Tel Profile.
The valid value range is 0 to 7, where 0 denotes PLAN1, 1 denotes
PLAN2, and so on. The default is -1, indicating that no Dial Plan file is
used.
Note:
 If the parameter is configured to select a Dial Plan index, the
settings of the parameter DigitMapping are ignored.
 If the parameter is configured to select a Dial Plan index from an
external Dial Plan file, the device first attempts to locate a matching
digit pattern in the Dial Plan file, and if not found, then attempts to
locate a matching digit pattern in the Digit Map rules configured by
the DigitMapping parameter.
 The parameter is also applicable to ISDN with overlap dialing.
 For E1 CAS MFC-R2 variants (which don't support terminating digit
for the called party number, usually I-15), the parameter and the
