Version 7.2 807 Mediant 1000B Gateway & E-SBC

User's Manual 48. Viewing Carrier-Grade Alarms

Field Description

Date

Date (DD/MM/YYYY) and time (HH:MM:SS) the alarm was raised.

 To delete all the alarms in the table:

1. Click the Delete History Table button; a confirmation message box appears.

2. Click OK to confirm.
