Version 7.2 153 Mediant 1000B Gateway & E-SBC
User's Manual 12. Network
The mapping of an application to its CoS and traffic type is shown in the table below:
Table 12-16: Traffic/Network Types and Priority
Application Traffic / Network Types Class-of-Service (Priority)
Debugging interface
Management Bronze
Telnet
Management Bronze
Web server (HTTP)
Management Bronze
SNMP GET/SET
Management Bronze
Web server (HTTPS)
Management Bronze
RTP traffic
Media Media Premium
RTCP traffic
Media Media Premium
T.38 traffic
Media Media Premium
SIP
Control Control Premium
SIP over TLS (SIPS)
Control Control Premium
Syslog
Management Bronze
SNMP Traps
Management Bronze
DNS client
Varies according to DNS settings:
 OAMP
 Control
Depends on traffic type:
 Control: Control Premium
 Management: Bronze
NTP
Varies according to the interface
type associated with NTP (see
''Assigning NTP Services to
Application Types'' on page 139):
 OAMP
 Control
Depends on traffic type:
 Control: Control Premium
 Management: Bronze
 To configure DiffServ (Layer-3 QoS) values per CoS:
1. Open the QoS Settings page (Setup menu > IP Network tab > Quality folder > QoS
Settings).
2. Click New; the following dialog box appears:
Figure 12-11: Configuring Class of Service
3. Configure DiffServ values per CoS according to the parameters described in the table
below.
4. Click Apply, and then save your settings to flash memory.
