Version 7.2 307 Mediant 1000B Gateway & E-SBC
User's Manual 16. Quality of Experience
2. Click New; the following dialog box appears:
Figure 16-7: Quality of Service Rules Table - Dialog Box
3. Configure a rule according to the parameters described in the table below.
4. Click Apply, and then reset the device with a save-to-flash for your settings to take
effect.
Table 16-6: Quality of Service Rules Table Parameter Descriptions
Parameter Description
Match
Index
[QualityOfServiceRules_Index]
Defines an index number for the new table row.
Note: Each row must be configured with a unique index.
IP Group
ip-group-name
[QualityOfServiceRules_IPGroup
Name]
Assigns an IP Group. The rule applies to all calls belonging to the
IP Group.
Rule Metric
rule-metric
[QualityOfServiceRules_RuleMetr
ic]
Defines the performance monitoring call metric to which the rule
applies if the metric's threshold is crossed.
 [0] Voice Quality = (Default) The device calculates MOS of
calls and if the threshold is crossed (i.e., poor quality), the
configured action (see 'Rule Action' parameter below) is done
for all new calls and for the entire IP Group.
 [1] Bandwidth
 [2] ACD
 [3] ASR
 [4] NER
 [5] Poor InVoice Quality = The device calculates MOS (and
TMMBR) of the call and if the threshold is crossed (i.e., poor
quality), the device uses a different IP Profile (see 'Rule
Action' parameter below) for the current call only (not the
entire IP Group).
Severity
severity
[QualityOfServiceRules_Severity]
Defines the alarm severity level. When the configured severity
occurs, the device performs the action of the rule.
 [0] Major (Default)
 [1] Minor
Note: If you configure the 'Rule Metric' parameter to ACD, ASR
or NER, you must configure the parameter to Major. For all other
'Rule Metric' parameter values, you can configure the parameter
