Version 7.2 319 Mediant 1000B Gateway & E-SBC
User's Manual 17. Control Network
The following procedure describes how to configure SRDs through the Web interface. You
can also configure it through ini file (SRD) or CLI (configure voip > srd).
 To configure an SRD:
1. Open the SRDs table (Setup menu > Signaling & Media tab > Core Entities folder >
SRDs).
2. Click New; the following dialog box appears:
Figure 17-7: SRDs Table - Add Dialog Box
3. Configure an SRD according to the parameters described in the table below.
4. Click Apply.
Table 17-4: SRDs table Parameter Descriptions
Parameter Description
General
Index
[SRD_Index]
Defines an index for the new table row.
Note: Each row must be configured with a unique index.
Name
name
[SRD_Name]
Defines an arbitrary name to easily identify the row.
The valid value can be a string of up to 40 characters.
Note:
 The parameter is mandatory.
 Each row must be configured with a unique name.
Sharing Policy
type
[SRD_SharingPolicy]
Defines the sharing policy of the SRD, which determines whether the
SRD shares its SIP resources (SIP Interfaces, Proxy Sets, and IP
Groups) with all other SRDs (Shared and Isolated).
 [0] Shared = (Default) SRD shares its resources with other SRDs
(Isolated and Shared) and calls can thus be routed between the SRD
and other SRDs.
 [1] Isolated = SRD does not share its resources with other SRDs and
calls cannot be routed between the SRD and other Isolated SRDs.
However, calls can be routed between the SRD and other Shared
SRDs.
For more information on SRD Sharing Policy, see Multiple SRDs for Multi-
tenant Deployments on page 323.
Note: The parameter is applicable only to the SBC application.
